Camera Details

Z Cam E2

Released: April 2018
Sensor: Micro Four Thirds (19 x 13 mm)
Lens Mount: MFT
Base Sensitivity: 500 ISO & 2500 ISO (Dual Native)
Weight: 800 g
Dimensions: 91 mm x 89 mm x 99 mm

Dynamic Range

69th best - max. 10.8 (SNR=2)

66th best - max. 11.9 (SNR=1)

Stops (SNR=2)	Stops (SNR=1)	Waveform	IMATEST	Patch Range	Codec	ISO	Framerate	Resolution	Gamma	Comment
10.8	11.9			13.1	ProRes HQ	500	25	4096x2160	Z-Log2
10.4	11.5			13.1	ProRes HQ	2500	25	4096x2160	Z-Log2

See Lab Test Article ...

Rolling Shutter

23rd best - min. 11.1 ms

Rolling Shutter	Image	Sensor Mode	Codec	Framerate	Resolution	Comment
11.1 ms		Micro Four Thirds	ProRes	25	4096x2160

See Lab Test Article ...

Recording Modes Overview

HD (1920 x 1080) @ max 240p, HEVC/H.265	HD (1920 x 1080) @ max 200p, HEVC/H.265	4K UHD (3840 x 1620) @ max 160p, HEVC/H.265
4K UHD (3840 x 1620) @ max 160p, ProRes (Proxy)	S16 (2704 x 1600) @ max 160p, HEVC/H.265	4K DCI (4096 x 1728) @ max 150p, HEVC/H.265
4K DCI (4096 x 1728) @ max 150p, ProRes (Proxy)	4K DCI (4096 x 2160) @ max 120p, ProRes (Proxy)	4K DCI (4096 x 1728) @ max 120p, HEVC/H.265
HD (1920 x 1080) @ max 120p, HEVC/H.265	S16 (2704 x 1600) @ max 120p, HEVC/H.265	HD (1920 x 1080) @ max 120p, ProRes (LT)

See complete Recording Modes & Times ...
