Canon EOS C80

Released: September 2024
Sensor: Full Frame 35mm (36 x 19 mm)
Lens Mount: RF
Base Sensitivity: 800, 3200 & 12800 ISO
Weight: 1310 g
Dimensions: 116 mm x 138 mm x 160 mm
COMPARE WITH CAMERA
chevron_right
chevron_right
COMPARE WITH CAMERA
chevron_right
chevron_right
Dynamic Range
Stops (SNR=2)Stops (SNR=1)WaveformIMATESTPatch RangeCodecISOFramerateResolutionGammaComment
10.711.815.5Canon RAW800256000x3164CLog2
9.5810.914.7Canon RAW3200256000x3164CLog2
8.259.7514Canon RAW12800256000x3164CLog2
13.314.414.6XF-AVC800254096x2160CLog2
11.312.814.6XF-AVC3200254096x2160CLog2
10.61216.1XF-AVC12800254096x2160CLog2
13.114.414.9XF-AVC800604096x2160CLog2
11.612.714.2XF-AVC3200604096x2160CLog2
10.61214.2XF-AVC12800604096x2160CLog2
Rolling Shutter
Rolling ShutterImageSensor ModeCodecFramerateResolutionComment
9.5 msFull SensorCanon RAW256000x3164
9.5 msFull SensorXF-AVC254096x2160
9.5 msFull SensorXF-AVC604096x2160
6.9 msS35 cropCanon RAW254368x2304
6.9 msS35 cropCanon RAW604368x2304
6.9 msS35 cropXF-AVC254096x2160
6.9 msS35 cropXF-AVC604096x2160
Recording Modes Overview
HD (1920 x 1080) @ max 180p, XF-AVC S Long GOPHD (1920 x 1080) @ max 180p, XF-AVC S Long GOPHD (1920 x 1080) @ max 180p, XF-AVC S Long GOP
2K DCI (2048 x 1080) @ max 180p, XF-AVC Long GOPHD (1920 x 1080) @ max 180p, XF-HEVC S Long GOP2K DCI (2048 x 1080) @ max 180p, XF-AVC S Long GOP
HD (1920 x 1080) @ max 180p, XF-HEVC S Long GOP2K DCI (2048 x 1080) @ max 180p, XF-AVC S Long GOP2K DCI (2048 x 1080) @ max 180p, XF-AVC S Long GOP
2K DCI (2048 x 1080) @ max 180p, XF-HEVC S Long GOPHD (1920 x 1080) @ max 180p, XF-AVC Long GOPHD (1920 x 1080) @ max 180p, XF-AVC S Long GOP
