Blackmagic Design PYXIS 6K

Released: April 2024
Sensor: Full Frame 35mm (35.93 x 23.95 mm)
Lens Mount: EF, L, PL
Base Sensitivity: 400 ISO & 3200 ISO (Dual Native)
Weight: 1500 g
Dimensions: 151 mm x 106 mm x 106 mm
COMPARE WITH CAMERA
chevron_right
chevron_right
COMPARE WITH CAMERA
chevron_right
chevron_right
Dynamic Range
Stops (SNR=2)Stops (SNR=1)WaveformIMATESTPatch RangeCodecISOFramerateResolutionGammaComment
11.512.814.7BRAW400256048x4032BMD Film
10.211.314.9BRAW3200256048x4032BMD Film
11.712.814.9BRAW400254096x2160BMD Film
Rolling Shutter
Rolling ShutterImageSensor ModeCodecFramerateResolutionComment
25 ms3:2 Open GateBRAW256048x4032
19.8 ms6K 17:9 DCIBRAW256048x3200
13.5 ms4K DCIBRAW254096x2160
Recording Modes Overview
HD (1920 x 1080) @ max 120p, Blackmagic RAW 5:1HD (1920 x 1080) @ max 120p, Blackmagic RAW Q1HD (1920 x 1080) @ max 120p, Blackmagic RAW Q5
HD (1920 x 1080) @ max 120p, Blackmagic RAW 8:1HD (1920 x 1080) @ max 120p, Blackmagic RAW Q3HD (1920 x 1080) @ max 120p, Blackmagic RAW 3:1
HD (1920 x 1080) @ max 120p, Blackmagic RAW 12:1HD (1920 x 1080) @ max 120p, Blackmagic RAW Q0HD (2112 x 1184) @ max 100p, Blackmagic RAW 3:1
HD (2112 x 1184) @ max 100p, Blackmagic RAW Q5HD (1920 x 1080) @ max 100p, Blackmagic RAW 3:1HD (2112 x 1184) @ max 100p, Blackmagic RAW Q3
