Camera Details

Blackmagic Design URSA Mini Pro 12K

Released: July 2020
Sensor: Super 35 mm (27.03 x 14.25 mm)
Lens Mount: PL, EF
Base Sensitivity: 800 ISO
Weight: 2600 g
Dimensions: 223 mm x 147 mm x 151 mm

Dynamic Range

42nd best - max. 11.8 (SNR=2)

48th best - max. 12.8 (SNR=1)

Stops (SNR=2)	Stops (SNR=1)	Patch Range	Codec	ISO	Framerate	Resolution	Gamma
11.8	12.8	16.6	BRAW	800	25	12288x6480	BMD Film
11.5	12.6	16.5	BRAW	800	25	8192x4320	BMD Film
11.3	12.5	16.6	BRAW	800	25	4096x2160	BMD Film

See Lab Test Article ...

Rolling Shutter

11th best - min. 7.8 ms

Rolling Shutter	Sensor Mode	Codec	Framerate	Resolution	Comment
15.7 ms	Super 35	BRAW	25	12288x6480	Full Sensor Area
7.8 ms	Super 35	BRAW	25	8192x4320	Full Sensor Area
7.8 ms	Super 35	BRAW	25	4096x2160	Full Sensor Area

See Lab Test Article ...

Recording Modes Overview

4K Super16 (4096 x 2160) @ max 239.76p, Blackmagic RAW 8:1	4K Super16 (4096 x 2160) @ max 239.76p, Blackmagic RAW 12:1	4K Super16 (4096 x 2160) @ max 239.76p, Blackmagic RAW 5:1
4K Super16 (4096 x 2160) @ max 239.76p, Blackmagic RAW 18:1	4K Super16 (4096 x 2160) @ max 200p, Blackmagic RAW 8:1	4K Super16 (4096 x 2160) @ max 200p, Blackmagic RAW 12:1
4K Super16 (4096 x 2160) @ max 200p, Blackmagic RAW 18:1	4K Super16 (4096 x 2160) @ max 200p, Blackmagic RAW 5:1	4K (4096 x 1704) @ max 160p, Blackmagic RAW 18:1
8K (8192 x 3408) @ max 160p, Blackmagic RAW 12:1	4K (4096 x 1704) @ max 160p, Blackmagic RAW 5:1	4K (4096 x 1704) @ max 160p, Blackmagic RAW 12:1

See complete Recording Modes & Times ...
